Flash Hot Faucet

Electric Heating Faucet DR11A-2L033J
Rated voltage:220-240V OR 110V        Rate frequency:50HZ/60HZ
Rate efficiency:2500-3300W            Water pressure:0.04-0.6Mpa
Water proof grade:IPX4                Power cord required:3×1.5m
Min Ammeter required:10.5A-16A OR 23A Heating system:Bare heating element

Clicks:3100





Name: Electric Heating Faucet DR11A-2L033J

No.: DR11A-2L033J

Product details

Rated voltage

220~240V

110V

Rated frequency

50Hz/60Hz

Rated power

2500-3300w

Rated current

10.5A-16A

23 A

Heating system

Bare heating element

Diameter of cable

3×1.5m

3×2.5m

Switch on water flow

80L/h

Usage water flow

80L/h-150 L/h

Max water pressure

0.6Mpa

Fit water pressure

0.04-0.6Mpa

Waterproof grade

IPX4

ApplicationSuitable for kitchen, bathroom, tube out of the wall; Can be rotated by 360, replacing the original faucet.

Main feature

A. European style, luxury, ultra-long life.

B. High sensitivity leakage protector, can cut off the bipolar power supply in 0.1 seconds.

C. 3 seconds fast heat, just like the ordinary faucet, easy to operate.

D. Inflow at the bottom, adjustable hot and cold water.

E. Electromechanical integration design, like the faucet but also the water heater.

Functional characteristics



High efficiency and energy saving, 3 seconds to be heating, simple installation, safe and durable.



Instant heating, changes in temperature at will

Turn on the faucet switch, hot water will come out in 2~3 seconds.mix cold and hot water by handle.



Saving electric & water ,cut down expenses

Instant water heating, full automatic control, no preheating, no wait, no waste, use hot water for one minute, only need 1 cent electric charge, economical and saving.



Prevent dry heating, adjustable water temperature

Ceramic water pressure switch design and unique overheating protection device, to ensure that no electrify when there is no water flow, to prevent dry heating accidents.

Easy for installation, easy to use

Convenient installation, replacing the original faucet ,in cold season, adjust the switch, there come out the hot water. In other seasons, adjust the switch to cold water, can be used as the traditional faucets.






There are a variety of vibrant colors for your choose:



Luxury gold with silver edge


Porcelain white with red edge



Blue with silver edge



Black gold





Grey green




Silver with golden edge





Champagne gold with silver edge





Bordeaux red with silver edge
